405nm BLUISH VIOLET DIODE LASER POINTERS
CLASS IIIa, IIIb Pointers



Specifications
Products Code SSL - LP - RGB - 450 - D
Wavelength [ nm ] 532 650 ± 5nm 450 ± 5nm
Output Power [ mW ] 1 - 100 1 - 100 1 - 100
Laser Power Safe Class II - IIIb II - IIIb II - IIIb
Operating Mode CW
Transverse Mode TEM00 TE00 TE00
Operating Temperature [ ºC ] -10 ~ +50
Operating Humidity [ % ] < 90
Storage Temperatures [ ºC ] -40 ~ +80
Storage Humidity [ % ] < 60
Beam Diameters At The Aperture [ mm ] ~ 4.5
Beam Divergence [ mrad ] ~ 1.3
Pointer Dimensions Diameter [ mm ] Ø: 38
Length [ mm ] 196
Optional Battery Li battery of 18650 × 1
Working Voltage [ VDC ] 3.7
Optics Glass lens both AR coated
Laser Mount Material Black Anodized Aluminum
Laser Gross Weight [ g ] [ Without Battery ] 340
Electrode Reverse Protection YES
Cooling Way Air
Expected Lifetime [ hours ] > 8000
Warranty Time [ months ] 6
Lead Time Quantity [ pcs ] < 100 < 500 < 1000< 5000
Time [ weeks ] 1 2 3 - 4

  Last Update Time: 2019. 02. 20
